Series 75 bozzello singolo con puleggia in alluminio

Series 75 bozzello singolo con puleggia in alluminio

Diametro puleggia: 75mm
Diametro massimo scotta: 14mm
Diametro perno: 8mm
Carico di lavoro massimo:1500kg
Carico di rottura: 3000kg
Peso 520 g

Series 75 AP blocks feature a self-lubricating Oilite® bronze bearing running on the polished stainless steel race to provide the high load capacity required of this range. For durability and a long service life, these blocks are the right choice for cruising and racing. For ultimate strength and durability cheek plates and load straps are made from grade 316 stainless steel . Cheek plates have a black chrome finish and are flared at the rope entry and exit points to minimise rope chafe. Bolt-through construction allows for servicing and sheave replacement or upgrade to alloy version.

Universal head can be fixed in either of two planes using the 'keeper' fitting provided, or free to swivel as required.

Mainsheet, halyard and spinnaker sheets on boats to 14m (46ft)
General applications on larger yachts

Self-lubricating Oilite® bronze bearing
Grade 316 stainless steel load straps
Black chromed Grade 316 stainless steel cheeks
Anodised aluminium sheave

Indicative product image. Actual product may differ slightly from that shown.
